M10 X 130mm COACH SCREW

A heavy steel washer, for general use with bolts and threaded bar (studding). BZP (Bright Zinc Plate) finish. Dimensions: 2mm x 24mm Diameter 11mm Bolt Hole: To suit M10 thread

Galvanised Truss Clip for constructing timber to timber framework. Precision formed and engineered for fast installation and maximum loads. - Suitable for securing 47mm wide timber - Overall Width - 105mm (including fixing wings) - Length - 100mm Install using 3.75 x 30mm square twist nails 12 nail holes / truss clip 1kg square twist nails installs approx. 29 truss clips

- 41mm x 41mm square spindles. - Pressure treated for durability. - Based on a gap of 99mm in between spindles, 7.14 spindles cover 1 metre.

Timber carcassing, general purpose building timber. - Machined from 47 x 150mm, finished size approx. 45 x 145mm - Smooth regularised finish - Grade C24 - Good quality, slow-grown softwood - Pressure-treated green Our carcassing timber is pressure treated for extended lifespan and protection against insect and fungal attack. Sourced from responsibly managed forests in Europe, the majority of our carcassing is milled in Sweden or Latvia where due to the colder climates the timber is slow grown resulting in a denser, straighter end product.

Treated timber carcassing for general building projects. - Machined from 47 x 100mm, finished size approx. 45 x 95mm - Smooth regularised finish - Grade C24 - Good quality, slow grown softwood - Pressure treated green

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing. Drill Bit Dia. - 8mm Anchor Length - 100mm Washer Size - 10mm (M10) Min Hole Depth - 55mm Min Over Drill Depth - 15mm Min. Embed Depth - 40mm Max. Fixture Thickness - 60mm Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt) Head Type - Hex Head, 15mm (Across Flats) Driver Type - Impact driver, socket, spanner Max Tightening Torque - 40Nm
